The Renogy 3000W Pure Sine Wave Inverter Charger can be used for multiple applications when going off-grid. A power inverter is an electrical device that transforms the DC power stored in a battery bank into standard household AC power for a user's electronic needs. This device can also charge and maintain a battery bank when connected to shore power and now compatible with Lithium batteries. With a low transfer time, power remains uninterrupted when switching from solar to shore power. This creates clean and silent energy without having to worry about losing access to connected devices and appliances. The Renogy 3000W Pure Sine Wave Inverter Charger is a perfect back-up power source!
- Robust and sleek design
- LCD and LED display used to view inverter status and programming features
- Offers high quality waveform with little harmonic distortion
- 4-Stage battery charger with configurable charging current
- 8 Pre-Set battery voltages including Lithium; User-defined option available
- Automatic generator start option
- Peak efficiency >90%
- Multiple electronic protections
MINIMUM 12V LITHIUM BATTERY BANK SIZING
The following are the minimum battery quantities to operate Renogy power inverters. This is ONLY for 12V applications.
| BATTERY BANK QTY/ INVERTER SIZE | 50AH | 100AH | 170AH |
|---|---|---|---|
| 700W | 1 | 1 | 1 |
| 1000W | 2 | 1 | 1 |
| 2000W | 4 | 2 | 1 |
| 3000W | 6 | 3 | 2 |
| INVERTER SPECIFICATIONS | |
|---|---|
| Continuous Power: 3000W | Surge Power (1 second): 9000W |
| AC Output Voltage Range: 100~120VAC configurable, 5V interval | Output Frequency (Nominal): 50/60 Hz |
| DC Input Voltage Range: 10~16 VDC | Output Waveform: Pure Sine Wave |
| Nominal Efficiency: > 90% Peak | No Load Power Consumption: Normal: <30W; Power Saving: <15W |
| CHARGER SPECIFICATIONS | |
|---|---|
| Output Current: 5-75A configurable, 5A intervals | Optimal Efficiency: >85% |
| Nominal Input Voltage: 120 VAC | Input Voltage Range: 90-138 VAC |
| Input Frenquency Range: 40Hz - 70Hz | Input Wave Form: Sine Wave (Utility or Generator) |
| TRANSFERSWITCH SPECIFICATIONS | |
|---|---|
| Transfer Time: ~ 10ms | Transfer Rating: 30A Automatic Transfer Switch |
| GENERAL SPECIFICATIONS | |
|---|---|
| Battery Types: GEL, AGM, SLA, FLD, CAL, LI, USER | Noise: <50dB |
| Operating Temperature: 0 ~ 40°C / 0 ~ 104°F | Dimensions: 20.1 x 11.2 x 7.6 in / 510 x 285 x 193 mm |
| Storage Temperature: -30 ~ 70°C / -22 ~ 158°F | Weight: 63.5 lbs / 28.8 Kg |
| Humidity: 0% ~ 95% |
WARRANTY INFORMATION
| Inverters |
2-year material and workmanship warranty |
| Accessories | 1-year material warranty |
